350.000 د.ع

DHI-HY-C102-4 Conventional Fire Alarm Control Panel is designed and manufactured in compliance with EN54 Parts 2 & 4 requirements. As the core of conventional fire alarm system, it cooperates with smoke detectors, heat detectors, sounder strobes, and manual call points to construct a fire alarm control system. With Ethernet, RS-485, and other IoT interface, it can integrate with other panels and connect platforms.

Datasheet_Conventional Fire Alarm Control Panel



التصنيف:

الوصف

– 90VAC to 270VAC main power supply ensures the stable operation

– 4 dry contacts make connection flexible

– Ethernet interfaces enables communication with IoT platform

– RS-485 interface contributes to convenient integration

– Record and export capacity of historical events for each of fire, fault and operation

Technical Specification

  • Number of Zones: 4
  • Zone Capacity: 32 detectors per zone
  • Main Power: AC90-240V/50Hz, 60Hz
  • Backup Power: 2 lead-acid batteries (12V/2.5Ah each)
  • Output Current: 2A
  • Sounder Output: Fault: 50dB – Alarm: 60dB
  • Fire Bell Output: DC 28V/500mA
  • Dimensions: 310.0 m
  • m×73.0 mm×227.0 mm (12.20″ × 2.87″ × 8.94″)
  • Weight: 3.5 kg : 5 kg (with 2 batteries)
  • Operating Temperature: –10°C to +50°C (+14°F to +122°F)
  • Operating Humidity: ≤ 95% RH (no condensation)
  • Protection Grade: IP30
  • installation: Wall mount
  • Compliance Standard: EN54-2,EN54-4
